Y&H 600W MPPT Function Pure Sine Wave Inverter Grid-Tie Inverter 220V Output 18V Input Micro On Grid Tie Inverter 18V 36 Solar Cells Blue GTI-600W-18V-220V-B - Intl

Smart grid tie inverter is a compact unit, which directly converts direct current into alternating current for powering appliances and/or office equipments and connecting to utility grid. The AC output from Smart Microinverter is synchronized and in phase with the utility grid. It is a key device of power generation systems such as PV power generation system, wind turbine power generation system. Smart Microinverter specially optimized design to work with modularization of DC power supplies which includes the mainstream solar modules, 18V (36 cells), 24V (60 cells) monocrystal and/or Polycrystalline solar panels, wind turbines and batteries. Smart Microinverters are stabilization, reliable and high conversion efficiency items. It is the best choice for PV power generation systems.

1. Unique circuit design, choice of import industrial electronic components, higher efficiency, more stable performance.

2. Creative MPPT technology, efficiency more than 99%, faster and more sensitive reaction, more reliable.

3. Parallel type design for DC input and modularization design for inverter, small volume, distributed installation, easy for system configuration, flexible for combination, strong expansibility of system.

4. Adopting high-frequency isolation transformer type, high efficiency, and high security.

5. Perfect electrical protection function.

6. Aluminum alloy housing, not rust, heat-resisting and cold-resistant as well as anti-corrosion.

7. Getting electronic circuit design, appearance design and other core technology patents.

Status Indications of LED

1. Red LED indicator lights up under any conditions include but not limited:

a) Low-voltage protection (DC input voltage lower than Min. input voltage of inverters),

b) Over-voltage protection (DC input voltage higher than Max. input voltage of inverters),

c) Over-temperature protection (inverters will shut down for power output when temperature of body of inverters higher than 65-75°C, and inverter will be automatically restart up when temperature down to 40-50°C.)

a) Power grid fault protection when 110VAC or 220VAC grid power outage and/or tripped.

b) Islanding protection: inverter will be automatically shut down for power output when disconnect with power grid.

c) Short-circuit protection: inverter stops work when output line short-circuits..

d) Red LED lights on for a while and then green LED lights on in one second when inverter starts to work.

2. Green LED indicator lights up under any conditions include but not limited:

a) Green LED flash: adjusting for power output, MPPT operating for tracking.

b) Green LED long light: indicates inverter locking-in Max. output power operation status.

c) When green LED flash from the bottom up in turns, it is indicates the inverter is locked at maximum power point as well as the output power is steady. The more power output, the faster running of green LED.

3. Please note that above operations only run at grid-connected status.
