LKV373 100m HDMI Extender Receiver with LAN Interface - 100 - 240V (Black)

Description:

This HDMI extender over CAT5e / 6 cable is designed to convert HDMI signal to standard TCP / IP and transimit by internet cable or Lan.With the advantage of TCP / IP standard, it can transmit HDMI signal source from HD STB, DVD, PS3, HDMI display card etc. to HD projector, DLP, LCD, LED and other audio visual equipments.

Main Features:
Extends HDMI up to 100 meters for 1080P over one CAT5
Follow the standard of IEEE - 568B
Support resolution up to 1080P
Support ethernet bandwidth: 100m
HDCP compliant
Extend by router connection or LAN connection, cable length requirements are as follows:
CAT 5 maximum 80 meters between two devices
CAT 5e maximum 100 meters between two devices
CAT 6 maximum 120 meters between two devices
Work temperature: -10 - 60 degrees
Link connector (sender / receiver): UTP / STP, CAT5e / 6
Power consumption: 3W (max) each
Relative humidity: 20% - 90%
Voltage range: 100 - 240V

Model: LKV373
Interface: HDMI,RJ45,DC 5V
Available color: Black

Package weight: 0.329 kg
Product size (L x W x H): 11.00 x 5.80 x 2.50 cm / 4.33 x 2.28 x 0.98 inches
Package size (L x W x H): 14.00 x 8.50 x 7.80 cm / 5.51 x 3.35 x 3.07 inches

Package Contents: 1 x HDMI Extender Receiver, 1 x Adapter, 1 x English Manual
