Digital LED Display Thermostat Controller(Grey)

Feature:

• Mini size, high quality temperature controller, Wide temperature measuring range, -50~+110 Degree Centigrade
• With large and clear LED display for better readability
• Multiple functions, such as Heating and Cooling control, Temperature Calibration function, Delay protection function
• All parameters can be set to default setting after short circuit
• Can be used for domestic freezer, water tanks, refrigerator, industrial chiller, boiler, steamer, industrial equipments and other temperature-controlled systems

Specification:

• Input Voltage: DC 12V
• Control Range: -55~120 Degree Centigrade
• Resolution:
  -9.9~99.9 Degree C: 0.1 Degree C
  Else Range: 1 Degree C
• Control Accuracy: 0.1 Degree C
• Temperature Accuracy: 0.2%FS
• Refresh Rate: 2 times / second
• Measurement Input: NTC（B3950=10K 0.5%）waterproof sensor (Cable Length: 1 meter)
• Output: Output Switch, Max. 10A
• Environment Requirement: -30~60 Degree C
• Humidity: 20%~85%
• Parameter Setting (P0~P8):
  -P0：Cooling / Heating mode
  -P1: Backlash Setting
  -P2：Highest Range Setting
  -P3：Lowest Range Setting
  -P4：Temperature Calibration
  -P5：Delay Start Time
  -P6：High Temperature Alarm
  -P7： Data Lock Switch
  -P8: Restore Factory Settings
• Size:
  -Complete Size: 77 x 35 x 88mm
  -Open-pore Size: 70.5 x 29mm
• Package Weight: 139g

Usage:

• Long-press "Set" button for 5 seconds to enter the internal parameter setting, then press Up/Down button to adjust P0~P8, and press "Rst" to Confim & Back.
