เครื่องควบคุมประจุ 10A 12V/24V LCD Display PWM Solar Panel Regulator Charge Controller USB LD558
- Visual LCD graphic symbol
- Automatic identification system voltage level
- Adjustable charge-discharge control parameters
- Multiple selection of battery
- Battery low voltage protection
- Overload & short circuit protection
เปรียบเทียบราคา เครื่องควบคุมประจุ 10A 12V/24V LCD Display PWM Solar Panel Regulator Charge Controller USB LD558
Specifications:
Model: CMTD-2410Rated charging current: 10A
Rated load current: 10A
Rated voltage: 12V/24V Auto
Max solar panel input voltage: ≤50V
USB Output: 5V 2A
Voltage of stop power supply: 10.5V/21.0V
Voltage of resume power supply: 12.2V/24.4V
Voltage of stop charging: 14.7V/29.4V
Working Temperature : -20~+60℃
size of Controller(L*W*H): 103×95×41mm
Net weight: 220g-230g
Features:
Visual LCD graphic symbolAutomatic identification system voltage level
Adjustable charge-discharge control parameters
Multiple selection of battery
Battery low voltage protection
Overload & short circuit protection
Brief key operation
Intelligent PWM charge mode
Settable operating modes of loads
Battery over temperature protection
Battery reverses polarity protection
With Dual USB 5V output
How to use it:
Connection:Open the top cover of the controller and connect the wire with terminals follow the diagram on the cover of it
1) Firmly and correctly connect the "+", "" poles of the battery to the corresponding ports of the controller (the third and the forth one from the left). When load indicator light flash once and will light after 30 seconds, which means that the connection is correct, and you can continue finishing following connection, otherwise the controller will be damaged
2) Firmly and correctly connect the "+", "" poles of the solar panel to the corresponding ports of the controller (the first and the second one from the left). The wrong connection will damage the controller
3) Firmly and correctly connect the "+", "" poles of the load to the corresponding ports of the controller (the fifth and the sixth one from the left)
Note: The controller should be connected to the battery first
Note:
1. Please carefully check and confirm the voltage of the components before connecting
2. The rated current of Solar panel and load must be less the than the rated current of controller
Electronic Protections:
Over dischargingOver charging
Load overload
Load short circuit
PV reverse polarity
Battery reverse polarity
Package Includes:
1 x Solar Charge Controller1 x Instruction Manual
